Wood CNC Machining Center with Disc-ty
Ref: SH-1325ATC Marca: GANGER
$ 75,000.00
Space for info
Lorem ipsum dolor sit amet, consectetur adipisicing elit. Ipsam, nisi.
CaracterÃsticas
Wood CNC Machining Center with Disc-type ATC SH-1325ATC
Machine features:
1.Siemens controlling system and servo
motor, Global Warranty Service.
2.Disk-type ATC with 8 tools,no need to
change tools manually during working, high efficiency. Applicable to workpieces
which need many different tools to finish.Intelligent controlling, working
process-Auto tool changing function.
3.Whole machine of high rigidity steel
structure,ensuring equipment’s steadiness and bearing capability of high
pressure.
Technical parameters | |||
Model | SH-1325ATC | SH-1530ATC | SH-2030ATC |
X/Y/Z Axis working size | 1300*2500*200mm | 1500*3000*200mm | 2000*3000*200mm |
Working table | Aluminum profile T slot/Vacuum absorption table | ||
X/Y/Z Axis transmission | X/Y Axis helical gear and rack, Z Axis Ball screw | ||
Spindle power | Italy HSD ATC Air-cooling spindle 9.0kw/12kw | ||
Max spindle speed | 24000rpm | ||
Collet/Blade diameter | ISO30 | ||
ATC type and capacity | Disc type ATC, 8 tools | ||
Driver system | Siemens servo motor | ||
Control system | Siemens control system | ||
Gross weight | 2500KGS | ||
Applicable industry and material:
Applicable industry: wood furniture
,wooden crafts processing industry, suitable for large panel cutting,large
relief carving products and large carpentry engraving.
Applicable material: solid wood panel,
artificial board,Acrylics,PVC,MDF,Plexiglass, plastic.etc non-metal panels.
