Wood CNC Router with ATC (Air-Cylinder
Ref: SH-1325Q3 Marca: IMASS
$ 75,000.00
Space for info
Lorem ipsum dolor sit amet, consectetur adipisicing elit. Ipsam, nisi.
Características
Wood CNC Router with ATC (Air-Cylinder type) SH-1325Q3
Machine Features
1.Air-cylinder type Auto tool changing,
high efficiency.3spindles are able to work alternately,
saving time of changing tool during
work. Suitable for the work which need three types cutters.
2. Imported main spare parts are
available.
3.Vacuum absorption zones could be
controlled through Siemens control system.
4.Large compatibility. CAD/CAM
designing software such as
Type3/ArtCAM/Castmate /Wentai and so
on.
Technical parameters | |||
Model | SH-1325Q3 | SH-1530Q3 | SH-2030Q3 |
X/Y/Z Axis working size | 1300*2500*200mm | 1500*3000*200mm | 2000*3000*200mm |
Working table | Vacuum absorption table with Solenoid Switch | ||
X/Y/Z Axis transmission | X/Y Axis Helical Gear and rack ,Z Axis Ball screw | ||
Spindle power | Air-cooled spindle 4.5kw*3 | ||
Max spindle speed | 18000rpm | ||
Collet/Blade diameter | ER32(2-20mm) | ||
ATC type and capacity | Air-cylinder ATC, 3 PCS | ||
Driver motor | Servo motor | ||
Control system | NC studio control system | ||
Gross weight | 1500-2000KGS | ||
Applicable industry and material:
Applicable industry: wood
furniture,wooden crafts processing industry, suitable for large
panel cutting,large relief carving
products and large carpentry engraving.
Applicable material: solid wood panel,
artificial board,Acrylics, PVC,MDF.
